Winch VR EVO 12-S 5440KG 12V
Winch VR EVO 12-S 5440KG 12V
The Warn VR Evo 12-S Black is a durable, IP68-rated winch with a 12,000 lb pull capacity, synthetic line, and tactical styling. Featuring a series-wound motor, 3-stage planetary gear, Albright® contactor, and both wired and wireless remote options, it offers reliable performance for vehicle recovery.
Shipping time: In stock. Ships in 3 - 5 days
Couldn't load pickup availability
Description
+
-
Description
The Warn winch VR EVO 12-S features IP68-rated waterproof construction, an ultra-reliable Albright® contactor inside a relocatable control pack, and a corded remote with 11.5' (3.5m) lead. With it’s fast line-speed and lower amp draw, the VR EVO winches are the hardest-working standard-duty winches, with tactical styling that looks great up front and at a price that won’t pull you out of your budget.
Warn Winch installation requirement
There are no specific installation requirement for the Warn VR EVO 12-S.
Warn Winch VR Evo 12-S specifications
- A powerful series-wound motor and planetary gear train deliver faster line speed under load, with lower amp draw
- IP68-rated waterproof winch construction keeps the elements out
- High-performance Albright contactor delivers maximum reliability
- Control packs can be relocated for low-profile installations
- Durable, one-piece cast-aluminium tie-plate for added strength and durability
- 2-in-1 wired and wireless remote
- Limited lifetime warranty for mechanical parts and 7 years on the electrical
| Type | Electric |
| Recommended Use | Vehicle Recovery |
| Mounting Location | Vehicle Mounted |
| Voltage | 12 Volt DC |
| Electrical Control Type | Albright Contactor |
| Motor Type | Series Wound |
| Drive Gear Type | 3-Stage Planetary |
| Gear Reduction Ratio | 234:01:00 |
| Free Spooling | Yes |
| Brake Type | Spring |
| Line Diameter (IN) | 3/8 Inch |
| Line Material | Synthetic |
| Length (FT) | 90 |
| Fairlead Type | Hawse |
| Remote Type | corded remote with 11.5' (3.5m) lead |
| Hole Quantity for mounting | 4 |
| Mounting Pattern Length (IN) | 10 Inch |
| Mounting Pattern Width (IN) | 4-1/2 Inch |
| Includes Mounting Hardware | Yes |
| Color | Black |
| Drum Material | Steel |
| Max Line Pull/ Line Speed | 12,000 pounds / 4.0 feet per minute |
| Max Amp Draw/ Line Pull | 396 Amps / 12,000 pounds |
Product disclaimer
Project Yonder does not accept any liability nor hold responsibility for the regulations you need to abide by or any problems you might encounter with this product.
Compatible with
+
-
Compatible with
- Mercedes Benz - Sprinter W907 (2018+)
- Volkswagen - Crafter 1st generation (2006 - 2017)
- Volkswagen - Crafter 2nd generation (2017+)
- Hymer - Free S Campus
- Dethleffs - Globetrail Performance
- Volkswagen - Grand California 600/680
- Hymer - Grand Canyon S
- Hymer - Grand Canyon S Crossover
- Westfalia - James Cook
- Yucon - K-Peak
- Hymer - ML-T Crossover
- Mercedes Benz - Sprinter W906 (2006 - 2018)
- Mercedes Benz - Sprinter W910 (2018+)
- Westfalia - Sven Hedin
- MAN - TGE (2017+)
- Yucon - V-City
- Hymer - Venture S
If your vehicle is not listed, you're unsure whether this product is compatible with your vehicle or would like further advice, please get in touch - hello@projectyonder.co.uk
Additional info
+
-
Additional info
- Shipping weight: 30 kg
- Shipping dimensions: 58 × 31 × 30 cm
- Material: Steel, Synthetic
