Retractable Hot Water Mixer Tap 'Dark Edition'

The Queensize Camper Retractable Hot Water Mixer Tap represents innovative space-saving design for vanlife water systems. UK exclusive at Project Yonder, this cleverly engineered tap features a retractable spout that collapses when not in use, maximising precious worktop space in compact van kitchens. The integrated hot water mixing function allows precise temperature control by blending hot and cold water supplies. Finished in the signature 'Dark Edition' aesthetic, this German-engineered component delivers both functionality and style to professional campervan conversions.

Key Features

• Retractable Design: Collapsible spout folds down when not in use
• Hot Water Mixing: Blends hot/cold sources for temperature control
• Space-Saving: Minimal footprint when retracted
• Dark Edition Finish: Sleek black/dark aesthetic throughout
• Premium Construction: Durable brass internals, quality materials
• Vanlife Optimised: Designed specifically for compact installations
• Temperature Control: Single-lever operation for heat adjustment
• German Engineering: Queensize Camper quality standards
• Easy Installation: Standard connections for straightforward setup
• Marine-Grade Durability: Built to withstand mobile living conditions

Technical Specifications

• Type: Retractable hot water mixer tap
• Operation: Single-lever mixing control
• Material: Brass body with dark coated finish
• Spout Height (Extended): Approximately 150-180mm
• Spout Height (Retracted): Approximately 60-80mm
• Base Diameter: Approximately 45-50mm
• Connection Type: Standard 3/8" or 1/2" threaded connections
• Temperature Rating: Suitable for hot water up to 60°C
• Pressure Rating: 1-3 bar operating pressure
• Finish: Dark Edition (black/dark grey)
• Weight: Approximately 600g
• Warranty: Queensize Camper standard warranty

Installation & Setup

Pre-Installation Requirements:

• Hot water system installed (diesel/gas/electric heater)
• Cold water supply line in place
• Worktop/sink cutout prepared
• Access to underside of worktop for connections

Basic Installation Steps:

1. Prepare Worktop: Drill mounting hole according to tap specifications
2. Position Tap: Insert tap body through worktop hole
3. Secure Base: Tighten mounting nut from underneath
4. Connect Water Lines: Attach hot water inlet (typically left)
5. Connect Cold Line: Attach cold water inlet (typically right)
6. Check Connections: Ensure all fittings are secure and sealed
7. Test Operation: Run water, check for leaks, test mixing function
8. Adjust Temperature: Set mixing ratio for comfortable output

Installation Time: 1-2 hours for standard setup

System Compatibility

Hot Water Systems:

• Webasto/Eberspächer diesel heaters with heat exchangers
• Truma/Alde gas heating systems
• Electric immersion heaters
• Combi boiler systems
• Instantaneous gas water heaters

Water Supply Systems:

• Pressurised pump systems (12V)
• Accumulator tank installations
• Direct pump feed setups
• Gravity-fed systems (with adequate pressure)

Van Compatibility:

• Mercedes Sprinter conversions
• VW T5/T6/T6.1 Transporter
• Ford Transit Custom
• Fiat Ducato
• Renault Trafic
• Custom campervan builds

Space-Saving Advantages

Retractable Design Benefits:

• Maximises Worktop Space: Folds down when not needed
• Reduces Clutter: Clean, unobtrusive appearance when retracted
• Protects Spout: Less vulnerable to damage during travel
• Flexible Usage: Extends only when water is needed
• Professional Aesthetic: Modern, minimalist design
• Travel-Friendly: Lower profile reduces rattle and movement risk

Ideal Applications:

• Compact van kitchens with limited counter space
• Galley-style layouts requiring maximised work area
• Dual-sink installations where one tap serves multiple basins
• High-traffic areas where extended spouts create obstacles
• Conversions prioritising clean lines and minimal visual clutter

Hot Water Mixing Function

Temperature Control:

• Single-lever design allows intuitive adjustment
• Pull up for flow rate, rotate for temperature
• Mix hot and cold sources to achieve desired heat
• Prevents scalding with balanced mixing capability
• Quick response for on-demand temperature changes

System Requirements:

• Both hot and cold water supplies must be connected
• Hot water temperature typically 50-60°C from heater
• Cold water supply provides mixing capability
• Adequate pressure in both lines ensures smooth mixing
• Check valve recommended to prevent backflow between supplies

Usage Tips

Daily Operation:

• Extend spout when washing dishes or filling containers
• Retract when finished to regain worktop space
• Start with cooler water, gradually increase temperature
• Allow hot water system to reach operating temperature first

Water Conservation:

• Use retracted position reminder to turn off tap
• Navy shower technique for efficient hot water use
• Pre-rinse with cold water where possible to conserve hot supply
• Monitor hot water tank capacity for extended use

Maintenance:

• Wipe spout and base after use to prevent water spots
• Check retraction mechanism periodically for smooth operation
• Descale aerator quarterly in hard water areas
• Inspect connections monthly for any weeping or drips

Care & Maintenance

Regular Cleaning:

• Clean dark finish with mild soap and soft cloth
• Avoid abrasive cleaners that can damage coating
• Dry thoroughly after cleaning to prevent water marks
• Use vinegar solution for limescale removal if needed

Retraction Mechanism:

• Extend and retract several times monthly to maintain smooth action
• Apply food-safe silicone lubricant if mechanism becomes stiff
• Check spring tension - should retract firmly but not violently
• Ensure base seal remains intact to prevent water ingress

Winter Storage:

• Drain all water from tap body if freezing temperatures expected
• Leave in extended position during storage to prevent seal compression
• Check connections for any frost damage before spring use
• Test mixing function after winter storage

Troubleshooting:

• Stiff retraction: Clean and lubricate mechanism
• Water dripping when retracted: Check spout seal, replace if worn
• Inconsistent temperature: Check both supply pressures are balanced
• Leaking at base: Tighten mounting nut, replace base gasket if needed
• Reduced flow: Clean aerator, check for supply line blockages

What Makes This Tap Special

The retractable design is what sets this mixer tap apart from standard vanlife fixtures. In the space-constrained environment of a campervan, every centimetre of worktop is precious. This innovative solution provides full hot water mixing capability when extended, then folds away to create a flush, unobtrusive surface when not in use. The Dark Edition finish ensures it complements modern van interiors, while German Queensize Camper engineering means it won't fail after a few months of use. Unlike cheap retractable taps that feel flimsy, this unit features solid brass construction with precise machining for smooth, reliable operation. Perfect for van builders who refuse to compromise between functionality and aesthetics.

Perfect for Mercedes Sprinter, VW T5/T6, and custom campervan hot water systems. Exclusively available at Project Yonder.
